Double-tap motorised lift
Double-tap the top control to raise or retract the unit.
V3L at a glance
Motorised power, faster charging and wireless convenience.
A slim motorised pop-up socket with two UK sockets, three USB ports and wireless charging.
Features
Power and USB
Two UK sockets, two USB-C ports and one USB-A port.
Wireless charging
Charge compatible Qi devices on the top surface at up to 10W.
Installation planning
65mm ±5mm opening
Plan a 65mm opening with a ±5mm tolerance. The top flange is approximately 80mm in diameter.
Allow 560mm below
The body extends approximately 504mm below the surface. Allow 560mm clear below the top surface, including cable routing.
Fitted UK plug
Supplied with an approximately 2m lead and fitted UK plug. No hardwiring is required for normal installation.
Important: The unit is IP20 when open and must not be treated as waterproof. Do not exceed 13A / 3,200W total.
It’s the finer details that set the best homes apart
Power when you need it, hidden when you don't. Choose a pop up power socket.
Qi wireless charging lid
Place your mobile device on the top for charging
Closed-lid protection
The closed lid includes a seal to help keep everyday splashes and debris away. The unit is IP20 when open; keep open connections dry and do not use the product in wet locations.
65mm ±5mm installation opening
Plan a 65mm opening with a ±5mm tolerance. The body extends approximately 504mm below the surface; allow 560mm clear including cable routing.
Plug and play
Supplied with an approximately 2m lead and fitted UK plug. No hardwiring is required for normal installation.
Elegant design, high quality build
Constructed with an extruded aluminium body and hardened-glass top
Form follows function
Two UK sockets, two USB-C ports, one USB-A port and a Qi wireless charging top.
Maximum output
13A / 3,200W total maximum. USB-C provides up to 30W and USB-A up to 18W when used alone; output is shared when multiple USB ports are used. Qi wireless charging is up to 10W.
Use as specified
Read the supplied instructions before installation and use. Keep within the stated total load and do not treat the open unit as water resistant.
Dimensions and details
Specifications, support and common questions.
Electrical, installation, delivery and support information is consolidated here so it is easier to scan.
Specifications
Electrical
240V AC, 50Hz; 13A and 3,200W total maximum.
USB charging
Two USB-C ports provide up to 30W and the USB-A port provides up to 18W when used alone. Output is shared when multiple USB ports are used. Qi wireless charging is up to 10W.
Construction
Black top, body and sockets; PVC, ABS and aluminium. IP20 when open. 24-month warranty.
Delivery, warranty and support
Technical sheet
Current dimensions, ratings and installation information for V3L-UK.
Shipping information
View current United Kingdom delivery options and estimated timeframes.
Frequently asked questions
How does it open?
Double-tap the top control to raise or retract the unit.
What opening is required?
Plan a 65mm opening with a ±5mm tolerance. The body extends approximately 504mm below the surface; allow 560mm clear below the top surface, including cable routing.
Is it waterproof?
No. The closed lid includes a seal to help keep everyday splashes and debris away, but the open unit is IP20.
